| Engine Model | OM 926 |
| Maximum Power (kW) | 180 kW @ 2200 rpm |
| Maximum Torque (Nm) | 850 Nm @ 1200 – 1600 rpm |
| No. of Cylinders, cc | 6, 7200 |
| Emission Standard | Bharat Stage VI – OBD-2 |
| Gear Box Model & Type | G 131, 9F+1R, Mechanical, Synchromesh Gears |
| Clutch Type | Single Dry Plate, Hydraulic Control |
| Clutch Dia, Wear (mm) | 395, 3.9 mm |
| Power Take Off | Auxiliary Fitment |
| Front Axle | IF 7.0 |
| Rear Axle | IR440-11 |
| Rear Axle Ratio | 4.778 – Standard Variant 4.3 – Car Carrier Variant |
| Service Brake | Pneumatic, Foot Operated, Dual Line with ABS |
| Parking Brake | Pneumatically Operated Hand Control Valve |
| Front Brake Size (mm) & Type | Ø 410 drum |
| Rear Brake Size (mm) & Type | Ø 410 drum |
| Service Brake | Pneumatic, Foot Operated, Dual Line with ABS |
| Parking Brake | Pneumatically Operated Hand Control Valve |
| Front Brake Size (mm) & Type | Ø 410 drum |
| Rear Brake Size (mm) & Type | Ø 410 drum |
| Cabin | Sleeper Cabin |
| Steering Type | Hydraulic Power Assisted |
| Battery Capacity | 120Ah |
| Voltage | 24V |
| Pattern & Size | Radial Tyres – 295/90R20 Tubeless Tyres – 295/80R22.5 |
| Gross Vehicle Weight – (kg) | 39500 kgs – Tandem Axle With Mechanical Suspension 37200 kgs – Car Carrier Trailers |
| Wheel Base (mm): | 3300 |
| Overall Length (mm): | 5780 |
| Overall Width (mm): | 2490 |
| Overall Height (mm) (CBC): | 2960 |
| Front Overhang (mm): | 1485 |
| Rear Overhang (mm): | 995 |
| Ground Clearance (mm): | 237 |
| Fuel Tank / Filling Capacity (L) | 455L/ 430L |
| Adblue Tank / Filling Capacity (L) | 60L/ 51L |
| TCD (m) | 12.8 m | ||||
| Maximum Gradeability (%) | 26.3% (4.778 RAR) 25.9% (4.3 RAR) | ||||
| Maximum Geared Speed (kmph) | 80 kmph | ||||
The BharatBenz 4023T is built for superior fuel efficiency, offering up to 6.5 KMPL, making it one of the most economical trucks in its category. Its advanced BS-VI compliant engine ensures reduced emissions and enhanced mileage without sacrificing power and performance.
The on-road price of the BharatBenz 4023T varies based on location and other factors. For the best price and offers, contact us today.
